High Quality Customized Fr4 Turnkey PCB Assembly Services Near me

turnkey pcb service
fr4 pcb assembly
high quality pcba
pcba
Product description: Assembly Turnkey PCB Assembly Low-Volume PCB Assembly Prototype PCB Assembly PCB PCBA Quick Quote SMT Stencil PCB Assembly Services
INQUIRY

High Quality Customized Fr4 PCB Assembly Services Near me

Quick detail:

Files and Requirment for PCB,PCBA quotation:

A BOM (Bill of Materials) with reference designators: component description, manufacturer’s name and part number.

PCB Gerber files.

A PCB fabrication drawing and PCBA assembly drawing.

Test procedures.

Any mechanical restrictions such as assembly height requirements

Technical requirement:

Professional surface-mounting and through-hole soldering technology

Various sizes like 1206, 0805, 0603 components SMT technology

ICT (In Circuit Test), FCT (Functional Circuit Test) technology

PCB assembly with UL, CE, FCC, RoHS approval

Nitrogen gas reflow soldering technology for SMT

High standard SMT and solder assembly line

High density interconnected board placement technology capacity

Main PCBA Production Equipment (8 SMT LINE 3DIP LINE)

ITEM	Device Name	Model	Brand Name	Qty	Remarks
1	Full Automatic Screen Printer	DSP-1008	DESEN	8
2	SMT Machine	YG200	YAMAHA	5	8 SMT Line
3	SMT Machine	YV100XG	YAMAHA	3
4	SMT Machine	YG100XGP	YAMAHA	19
5	SMT Machine	YV88	YAMAHA	5
6	Reflow Soldering	8820SM	NOUSSTAR	4
7	Reflow Soldering	XPM820	Vitronics Soltec	3
8	Reflow Soldering	NS-800 II	JT	1
9	Solder Paste Inspection	REAL-Z5000	REAL	1
10	Automatic Optical Inspection System	B486	VCTA	3
11	Automatic Optical Inspection System	HV-736	HEXI	5
11	X-Ray	AX8200	UNICOMP	1
12	Universal 4*48-pindrive concurrent multiprogramming system	Beehive204	ELNEC	3
13	Automatic Plug-In machines	XG-3000	SCIENCGO	2
14	Automatic wave soldering system	WS-450	JT	1	3 DIP LINE
15	Automatic wave soldering system	MS-450	JT	2	3 DIP LINE

PCBA (PCB Assembly) Process Capability:

Technical Requirement	Professional Surface-mounting and Through-hole soldering Technology
	Various sizes like 1206,0805,0603 components SMT technology
	ICT(In Circuit Test),FCT(Functional Circuit Test) technology
	PCB Assembly With UL,CE,FCC,Rohs Approval
	Nitrogen gas reflow soldering technology for SMT
	High Standard SMT&Solder Assembly Line
	High density interconnected board placement technology capacity
Quote&Production Requirement	Gerber File or PCB File for Bare PCB Board Fabrication
	Bom(Bill of Material) for Assembly,PNP(Pick and Place file) and Components Position also needed in assembly
	To reduce the quote time, please provide us the full part number for each components,Quantity per board also the quantity for orders.
	Testing Guide&Function Testing method to ensure the quality to reach nearly 0% scrap rate
OEM/ODM/EMS Services	PCBA, PCB assembly: SMT & PTH & BGA
	PCBA and enclosure design
	Components sourcing and purchasing
	Quick prototyping
	Plastic injection molding
	Metal sheet stamping
	Final assembly
	Test: AOI, In-Circuit Test (ICT), Functional Test (FCT)
	Custom clearance for material importing and product exporting
Other PCB Assembly Equipments	SMT Machine: SIEMENS SIPLACE D1/D2 / SIEMENS SIPLACE S20/F4
	Reflow Oven: FolunGwin FL-RX860
	Wave Soldering Machine: FolunGwin ADS300
	Automated Optical Inspection (AOI): Aleader ALD-H-350B,X-RAY Testing Service
	Fully Automatic SMT Stencil Printer: FolunGwin Win-5
